You are in: Chain and accessories / Chain and chain slings grade 100 / Chain Grade 100

Chain Grade 100

- Chains Grade 100 (G100) are manufactured from high-strength grade 100 steel, thanks to which they withstand up to 25% greater load compared to the same diameter grade 80 chain
- Due to their lower weight compared to class 80, they are preferred by operators when working with heavy loads
- Operating temperature range from -40 ºC to +200 ºC
- Safety factor 4:1
- In accordance with standard ASTM A973, EN818-2

Description
Inquiry

The load capacity chain Grade 100 is maintained at higher working temperatures (200 ° C) without reducing it. Above this temperature, the load capacity percentage decreases. Grade 100 chain is ideal for handling heavy loads due to the lower dead weight and greater load capacity compared to Grade 80.
