Master link assembly G80

- Certified master link class G80 - main component in the production of rope, chain and polyester slings.
- Made of high strength grade 80 steel
- The triple master link Grade 80, suitable for three- and four-leg systems, being connected directly in the manufacturing process for wire rope and polyester slings and through connecting links for chain slings
- 4:1 safety factor
- In accordance with standard EN1677-4
- Load capacity from 2.36t to 100t

Code:	WLL:	Net weight:

ARD-OD-02.36	2.36 t	1.18 kg
ARD-OD-03.15	3.15 t	1.24 kg
ARD-OD-04.25	4.25 t	2.20 kg
ARD-OD-06.70	6.70 t	3.40 kg
ARD-OD-11.20	11.20 t	6.10 kg
ARD-OD-17.00	17.00 t	9.98 kg
ARD-OD-21.20	21.20 t	18.90 kg
ARD-OD-26.50	26.50 t	22.60 kg
ARD-OD-31.50	31.50 t	25.20 kg
ARD-OD-45.00	45.00 t	34.26 kg
ARD-OD-50.00	50.00 t	40.00 kg
ARD-OD-63.00	63.00 t	66.46 kg

Description
Inquiry

Heavy duty tested and certified grade 80 master link assembly suitable for multi leg overhead lifting applications. We recommend only using Grade 80 Master Links with Grade 80 Components.
